Water Ripple Bamboo Veneer BCW-WR | 3D Panel

Name: Bamboo Charcoal Wood Veneer - Water Ripple
Brand: Li'en
SKU: BCW-WR
Availability: InStock

01

Overview

BCW-WR is an 8 mm bamboo charcoal board with a flowing water ripple relief pressed into a sealed decorative film. The pattern is a shallow three-dimensional wave rather than a printed line, so the surface catches light differently as the viewer moves. Sheets measure 1220 x 2800 mm, and the relief can run along the short or the long edge.

The finish suits hotel lobbies and reception desks, retail brand backdrops, banquet rooms and ceiling bulkheads, where lighting is part of the design. The core is rigid and moisture resistant, panels fix with adhesive or concealed clips, and the sealed relief wipes clean with a damp cloth.

Material	Bamboo charcoal composite core with 3D water ripple decorative film
Standard Size	1220 x 2800 mm (2440 / 2900 mm on request)
Thickness	8 mm (5 mm and 9 mm available)
Surface Finish	Three-dimensional water ripple relief, low-sheen sealed film
Color Range	Ripple walnut, ripple oak, ripple ebony, ripple teak, ripple grey ash, ripple champagne
Fire Rating	B1 (GB 8624)
Installation	Construction adhesive or concealed clip fixing, dry installation
MOQ	300 m2 per stock color, 500 m2 for custom colors

02

Product Features

Light and Shadow Depth

The relief breaks up reflections along the wall, so highlights travel across the panel as the lighting or the viewer moves.

Carved Look, Flat Panel

The ripple is embossed into the film, so a wall gets sculpted depth without the weight, wide joints and cost of carved timber.

8 mm Rigid and Dry

The composite core holds the relief flat across long walls and resists moisture, so the wave pattern stays even from panel to panel.

Textured, Easy to Clean

The relief is sealed under a smooth top coat, so dust lifts with a damp cloth and the wave pattern does not trap dirt.

03

Specifications

Sizes, thicknesses and finishes can be customized for OEM orders — send us your target specification and we will confirm feasibility.

Material	Bamboo charcoal composite core with 3D water ripple decorative film
Standard Size	1220 x 2800 mm (2440 / 2900 mm on request)
Thickness	8 mm (5 mm and 9 mm available)
Surface Finish	Three-dimensional water ripple relief, low-sheen sealed film
Color Range	Ripple walnut, ripple oak, ripple ebony, ripple teak, ripple grey ash, ripple champagne
Fire Rating	B1 (GB 8624)
Installation	Construction adhesive or concealed clip fixing, dry installation
MOQ	300 m2 per stock color, 500 m2 for custom colors

04

Colors & Finishes

Screen colors are indicative only — request a physical color card for accurate matching.

Ripple Walnut

Ripple Oak

Ripple Ebony

Ripple Teak

Ripple Grey Ash

Ripple Champagne

05

Applications

Hotel lobby and reception walls

Retail brand backdrops

Banquet and club interiors

Ceiling and bulkhead panels

06

Installation

Confirm the relief direction on the shop drawing, then set the first panel from the wall centre.

Keep the protective film on while cutting; a fine-tooth blade leaves a clean edge on the embossed surface.

Fix with construction adhesive on a flat substrate, or use concealed clips where panels must be removable.

Line up the wave direction panel to panel, seal the joints, peel the film and wipe the surface clean.

Packing & Loading

Panels are separated by foam sheets and stacked face to face, with the relief protected by the factory film.
Pallets are steel-strapped and labeled with model, color, relief direction, quantity and batch number.
A 20 ft container holds about 300 m2 of 8 mm ripple board in 2800 mm length, depending on packing.

Loading & documents

We photograph every container during loading and send the packing list before the vessel sails.

07

Bamboo Charcoal Wood Veneer - Water Ripple — Product FAQ

The wave is embossed into the decorative film, so it has real depth of roughly 0.3-0.5 mm without cutting into the core. That keeps the panel light and flat, and avoids the open grain that traps dust in carved timber.

That is where it works best. Light grazing the relief creates a moving band of highlight and shadow. We recommend a mock-up panel under the actual fixture before the wall is fixed, because fixture spacing changes the effect.

Relief direction is set at production and marked on every panel. Installers align the wave line across joints so the wall reads as one surface. For long runs, order the full quantity in one batch to keep the tone identical.

The relief is sealed with a smooth top coat, so dust does not settle into open grain. A soft damp cloth worked along the wave direction is enough, and abrasive pads or solvent cleaners should be avoided.
